Push-button with light TL 216 2p 16A BLUE 002422224 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002422224
- Description:
- *TL 216 2p 16A BLUE
- Class name:
- Push-button with light
- Catalogue Group:
- Push-button
- Catalogue subgroup:
- Push-button with control light TL
- Function:
- Push-button with control light
- Rated current (A):
- 16A
- Rated DC voltage (V):
- 24V
- Number of poles:
- 2
- IP rating:
- IP20
- Max input cross-section (mm²):
- 6mm²
- Rated Frequency (Hz):
- 50Hz/60Hz
- Standards:
- IEC/EN 60947-1,IEC/EN 60947-3
- Utilization category:
- AC-22A
Documents
Logistic Data
Product
- Net weight of the product
- 0.103 kg
- Customs tariff
- 85365080
- logis_net_width
- 18 mm
- logis_net_height
- 84 mm
- logis_net_depth
- 73 mm
Basic packaging
- Basic packaging quantity
- 12
- EAN code for a basic packaging
- 3838895297864
- Basic packaging weight
- 1.2 kg
Transport packaging
- Transport packaging quantity
- 108
- EAN code for a transport packaging
- 3838895297871
- Transport packaging weight
- 11.1 kg
- Pallet quantity
- 7020
ETIM Clasification
- Classification
- EC001546
- Class name
- Push button for distribution board
- Voltage type
- AC
- With signal lamp
- Yes
- Colour calotte
- Blue
- Lamp type
- Glow lamp
- Lamp socket
- E10
- Width in number of modular spacings
- 1
- Built-in depth
- 68mm
- Degree of protection (IP)
- IP20
