Cam switch ECS3-02 004771618
Specifications
- ETI Code:
- 004771618
- Description:
- ECS3-02
- Class name:
- Cam switch
- Function:
- Non-illuminated actuators
- Type:
- Compact integral actuators NC
Documents
Logistic Data
Product
- Net weight of the product
- 1.94 kg
- Customs tariff
- 85389099
Basic packaging
- Basic packaging quantity
- 20
- EAN code for a basic packaging
- 3838895874898
- Basic packaging weight
- 0.025 kg
Transport packaging
- Transport packaging quantity
- 150
- EAN code for a transport packaging
- 3838895874904
- Transport packaging weight
- 9.05 kg
- Pallet quantity
- 5550
ETIM Clasification
- Classification
- EC001029
- Class name
- Selector switch, complete
- Number of switch positions
- 3
- Type of control element
- Short thumb-grip
- Colour button
- Black
- Hole diameter
- 22,5mm
- Spring-return
- No
- Degree of protection (IP)
- IP65
- Supply voltage
- 240…240V
- Number of contacts as normally closed contact
- 2
- Type of electric connection
- Screw connection
- Material front ring
- Plastic
- Colour front ring
- Black
ECS3-02
