Fuse link CH22x58 gG 25A/690V 002640013 Obsolete
This product is obsolete and has been replaced with CH22x58 gG 25A/690V.
Compare products
Specifications
- ETI Code:
- 002640013
- Description:
- *CH22x58 gG 25A/690V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- 22x58
- Rated current (A):
- 25A
- Rated AC voltage (V):
- 690V
- Characteristics:
- gG
- Breaking capacity AC (kA):
- 80kA
- Application:
- For cable protection
- Power dissipation (W):
- 4.4W
- Standards:
- IEC 60269-1,IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895581314
- Net weight of the product
- 52 g
- Customs tariff
- 85361050
- logis_net_width
- 22 mm
- logis_net_height
- 58 mm
- logis_net_depth
- 22 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895138990
- Basic packaging weight
- 0.52 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895165934
- Transport packaging weight
- 26.3 kg
- Pallet quantity
- 26000
*CH22x58 gG 25A/690V
