Miniature circuit breaker ETIMAT P10-QC 1p+N D3 001906145
Specifications
- ETI Code:
- 001906145
- Description:
- ETIMAT P10-QC 1p+N D3
- Class name:
- Miniature circuit breaker
- Rated current (A):
- 3
- Tripping characteristic:
- D
- Number of poles:
- 1+N
- Short circuit capacity (kA):
- 10
- Voltage type:
- AC
- Rated voltage (V):
- 240
- Rated Frequency (Hz):
- 50/60
- Rated impulse withstand voltage Uimp (kV):
- 6
- Rated cross section:
- 1…4
- Standards:
- 60898-1, 60947-2
- Function:
- MCB
Documents
Logistic Data
Product
- Net weight of the product
- 249 g
- Customs tariff
- 85362010
ETIM Clasification
- Classification
- EC000042
- Class name
- Miniature circuit breaker (MCB)
- Release characteristic
- D
- Number of poles (total)
- 2
- Number of protected poles
- 1
- Rated current
- 3A
- Rated voltage
- 240V
- Rated insulation voltage Ui
- 500V
- Rated impulse withstand voltage Uimp
- 4kV
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
- 10kA
- Voltage type
- AC
- Frequency
- 50…60Hz
- Current limiting class
- 3
- Suitable for flush-mounted installation
- Yes
- Concurrently switching neutral conductor
- Yes
- Over voltage category
- 3
- Pollution degree
- 2
- Additional equipment possible
- No
- Width in number of modular spacings
- 2
- Built-in depth
- 70mm
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -60…70°C
- Connectable conductor cross section multi-wired
- 1…4mm²
- Connectable conductor cross section solid-core
- 1…4mm²
