Molded Case Circuit Breaker EB2 250/3L 160A 3p 004671071
Specifications
- ETI Code:
- 004671071
- Description:
- EB2 250/3L 160A 3p
- Class name:
- Molded Case Circuit Breaker
- Catalogue Group:
- EB2
- Rated current (A):
- 160
- Number of poles:
- 3
- Connection type:
- FRONT
- Rated impulse withstand voltage Uimp (kV):
- 8
- Rated short-circuit breaking capacity at 415V Icu/Ics (kA):
- 25/19
- Rated operational voltage AC (V):
- 690V
- Rated operational voltage DC (V):
- 250V
- Rated insulation voltage (V):
- 800
- Thermal adjustment:
- 0,63-1
- Magnetic adjustment:
- 6-13
- Adjustable or fixed:
- adjustable
- Standards:
- 60947
Documents
Logistic Data
Product
- Net weight of the product
- 1.5 kg
- Customs tariff
- 85362090
- logis_net_width
- 105 mm
- logis_net_height
- 165 mm
- logis_net_depth
- 92 mm
Transport packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 3838895409731
- Transport packaging weight
- 1.5 kg
- Pallet quantity
- 533
ETIM Clasification
- Classification
- EC000228
- Class name
- Power circuit-breaker for trafo/generator/installation protection
- Rated permanent current Iu
- 160A
- Rated voltage
- 415…415V
- Rated short-circuit breaking capacity lcu at 400 V, 50 Hz
- 25kA
- Overload release current setting
- 128…160A
- Adjustment range undelayed short-circuit release
- 960…2080A
- Integrated earth fault protection
- No
- Type of electrical connection of main circuit
- Screw connection
- Device construction
- Complete device in housing
- Suitable for DIN rail (top hat rail) mounting
- No
- DIN rail (top hat rail) mounting optional
- No
- Number of poles
- 3
- Position of connection for main current circuit
- Front side
- Type of control element
- Toggle
- Complete device with protection unit
- Yes
- Motor drive integrated
- No
- Motor drive optional
- Yes
- Degree of protection (IP)
- IP20
