Fuse link CH10x85 gPV 5A/1500V DC UL 002625239 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002625239
- Description:
- *CH10x85 gPV 5A/1500V DC UL
- Class name:
- Fuse link
- Type:
- CH
- Size:
- 10x85
- Rated current (A):
- 5A
- Rated DC voltage (V):
- 1500V
- Characteristics:
- gPV
- L/R (ms):
- 2ms
- Breaking capacity DC (kA):
- 10kA
- Application:
- For protection of photovoltaic modules
- Power dissipation (0,7x In) (W):
- 1.2W
- Power dissipation (W):
- 3W
- Operating joule integral (A2s):
- 33.2
- Prearcing joule integral (A2s):
- 10.6
- Standards:
- IEC 60269-6,UL 2579,UL 248-1
- UL certificate:
- E347771
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895911012
- Net weight of the product
- 16.1 g
- Customs tariff
- 85351000
- logis_net_width
- 10 mm
- logis_net_height
- 85 mm
- logis_net_depth
- 10 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895672449
- Basic packaging weight
- 0.162 kg
Transport packaging
- Transport packaging quantity
- 210
- EAN code for a transport packaging
- 3838895672456
- Transport packaging weight
- 3.7 kg
- Pallet quantity
- 35700
ETIM Clasification
- Classification
- EC000035
- Class name
- Miniature fuse
- Rated current
- 5A
