Fuse link NHU3L/MS gPV 400A/1500V DC UL 004110736
Specifications
- ETI Code:
- 004110736
- Description:
- NHU3L/MS gPV 400A/1500V DC UL
- Class name:
- Fuse link
- Type:
- NH-U
- Size:
- NH3L
- Rated current (A):
- 400A
- Rated DC voltage (V):
- 1500V
- Characteristics:
- gPV
- L/R (ms):
- 3ms
- Breaking capacity DC (kA):
- 50kA
- Application:
- Fuse link for DC application
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 67W
- Power dissipation (0,7x In) (W):
- 26.8W
- Operating joule integral (A2s):
- 450000
- Prearcing joule integral (A2s):
- 85000
- Standards:
- IEC 60269-6,UL 248-19
Documents
Logistic Data
Product
- Net weight of the product
- 1980 g
- Customs tariff
- 85351000
- logis_net_width
- 73 mm
- logis_net_height
- 198 mm
- logis_net_depth
- 88 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895868477
- Basic packaging weight
- 1.36 kg
Transport packaging
- Transport packaging quantity
- 9
- EAN code for a transport packaging
- 3838895868484
- Transport packaging weight
- 12.59 kg
- Pallet quantity
- 468
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 400
- Rated voltage
- 1500
- Voltage type
- DC
- Rated switching capacity
- 50
- Utilization category
- gPV (photovoltaic protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
