Fuse link NH00/K 315A/250V DC 004110139
Specifications
- ETI Code:
- 004110139
- Description:
- NH00/K 315A/250V DC
- Class name:
- Fuse link
- Type:
- NH-K
- Size:
- NH00
- Rated current (A):
- 315A
- Rated DC voltage (V):
- 250V
- Characteristics:
- gR
- L/R (ms):
- 20ms
- Breaking capacity DC (kA):
- 25kA
- Application:
- Fuse link for DC application
- Indicator:
- Striker pin status indicator
- Power dissipation (W):
- 21.2W
- Standards:
- IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895760795
- Net weight of the product
- 220 g
- Customs tariff
- 85361090
- logis_net_width
- 29 mm
- logis_net_height
- 87 mm
- logis_net_depth
- 60 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895595076
- Basic packaging weight
- 0.64 kg
Transport packaging
- Transport packaging quantity
- 54
- EAN code for a transport packaging
- 3838400141019
- Transport packaging weight
- 12.8 kg
- Pallet quantity
- 2808
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH00
- Rated current
- 315
- Rated voltage
- 250
- Voltage type
- DC
- Rated switching capacity
- 25
- Utilization category
- gR (general purpose semiconductor protection)
- Type of fuse status indicator
- Other
- Insulated metal gripping lugs (IMGL)
- No
NH00/K 315A/250V DC
