Fuse link NHG3L/M aR 1000A/1000V DC 004305637
Specifications
- ETI Code:
- 004305637
- Description:
- NHG3L/M aR 1000A/1000V DC
- Class name:
- Fuse link
- efuse:
- 1
- Size:
- NH3L
- Type:
- NH-G
- Rated current (A):
- 1000
- Rated DC voltage (V):
- 1000
- Characteristics:
- aR
- L/R (ms):
- 1
- Breaking capacity DC (kA):
- 30
- Application:
- Fuse link for DC application
- Indicator:
- Centre trip indicator for MK
- Power dissipation (W):
- 154
- Operating joule integral (A2s):
- 1.600.000
- Prearcing joule integral (A2s):
- 900.000
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- Customs tariff
- 85361090
- logis_net_width
- 74 mm
- logis_net_height
- 87 mm
- logis_net_depth
- 74 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895670568
- Basic packaging weight
- 1.45 kg
Transport packaging
- Transport packaging quantity
- 9
- EAN code for a transport packaging
- 3838895670575
- Transport packaging weight
- 13.4 kg
- Pallet quantity
- 9
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 1000
- Rated voltage
- 1000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Centre fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
