Fuse link NHS2/394/M aR 160A/4000V DC 004735603
Specifications
- ETI Code:
- 004735603
- Description:
- NHS2/394/M aR 160A/4000V DC
- Class name:
- Fuse link
- efuse:
- 1
- Size:
- NH2
- Type:
- NH-S
- Rated current (A):
- 160
- Rated DC voltage (V):
- 4000
- Characteristics:
- aR
- L/R (ms):
- 15
- Breaking capacity DC (kA):
- 30
- Application:
- Fuse link for DC link protection of railway inver
- Dimensions:
- S394mm
- Indicator:
- Centre trip indicator for MK
- Power dissipation (W):
- 100
- Operating joule integral (A2s):
- 55.000
- Prearcing joule integral (A2s):
- 5.800
- Standards:
- IEC 60269-4 , IEC 60077-5
Documents
Logistic Data
Product
- Customs tariff
- 85351000
- logis_net_width
- 66 mm
- logis_net_height
- 419 mm
- logis_net_depth
- 73 mm
Transport packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 3838895689713
- Transport packaging weight
- 3.99 kg
- Pallet quantity
- 140
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 160
- Rated voltage
- 4000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Centre fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
