Fuse link NH1 gG 160A/400V MET 004113838

Specifications

ETI Code:
004113838
Description:
NH1 gG 160A/400V MET
Class name:
Fuse link
efuse:
1
Type:
NH
Size:
NH1
Rated current (A):
160
Characteristics:
gG
Application:
As metering fuse with strip fuse switch disconnector and fuse switch disconnector
Indicator:
Top fuse status indicator
Power dissipation (W):
9
Standards:
IEC EN 60269-1

Documents

Product

EAN code for a single product

Net weight of the product
0.5  kg
Customs tariff
85361090

Level 1 Packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895618317
Basic packaging weight
0.5  kg

Level 2 Packaging

Transport packaging quantity
26
EAN code for a transport packaging
3838895618324
Transport packaging weight
13.5  kg
Pallet quantity
1352
Classification
EC000055
Class name
Low Voltage HRC fuse
Construction size
NH1
Rated current
160
Rated voltage
400
Voltage type
AC
Rated switching capacity
50
Utilization category
gL/gG (cable protection/equipment protection)
Type of fuse status indicator
Top fuse status indicator
ETIM Classification – Version 7.0
