Center-off change-over switch SS 225 2p 25A 002421422 Obsolete
This product is obsolete and has been replaced with *SSG 225 2pol 25A.
Compare products
Specifications
- ETI Code:
- 002421422
- Description:
- *SS 225 2p 25A
- Class name:
- Center-off change-over switch
- Catalogue Group:
- Control switch
- Catalogue subgroup:
- Change-over switch 1-0-2
- Function:
- Center-off change-over switch
- Rated current (A):
- 25
- Rated AC voltage (V):
- 400
- Rated DC voltage (V):
- 24
- Number of poles:
- 2
- IP rating:
- IP20
- Max input cross-section (mm²):
- 1x6 mm² / 2x2,5 mm², max. 1 Nm
- Rated Frequency (Hz):
- 50/60 Hz
- Standards:
- IEC/EN 60947-1, IEC/EN 60947-3
- Utilization category:
- AC-22A
Documents
Logistic Data
Product
- Customs tariff
- 85365080
Basic packaging
- Basic packaging quantity
- 12
- EAN code for a basic packaging
- 3838895297406
- Basic packaging weight
- 1.25 kg
Transport packaging
- Transport packaging quantity
- 108
- EAN code for a transport packaging
- 3838895297413
- Transport packaging weight
- 11.57 kg
- Pallet quantity
- 7020
ETIM Clasification
- Classification
- EC002611
- Class name
- Control switch
- Number of poles
- 2
- Max. rated operation voltage Ue AC
- 400V
- Rated permanent current Iu
- 25A
- Number of switch positions
- 3
- With zero (off) position
- Yes
- With retraction in 0-position
- No
- Device construction
- Built-in device
- Width in number of modular spacings
- 1
- Complete device in housing
- Yes
- Type of control element
- Rocker lever
- Degree of protection (IP), front side
- IP20
*SS 225 2p 25A
