Switch with lamp SL 225 2p 25A 002421222 Obsolete
This product is obsolete and has been replaced with *SLG 225 2pol 25A.
Compare products
Specifications
- ETI Code:
- 002421222
- Description:
- *SL 225 2p 25A
- Class name:
- Switch with lamp
- Catalogue Group:
- Control switch
- Catalogue subgroup:
- Switch 1-0, Switch 1-0 with control light
- Function:
- Switch with control light
- Rated current (A):
- 25
- Rated DC voltage (V):
- 24
- No. Of poles:
- 2
- IP rating:
- IP20
- Max input cross-section, mm2:
- 1x6mm2 / 2x2,5mm2 , max 1Nm
- Rated Frequency (Hz):
- 50/60 Hz
- Standards:
- IEC/EN 60947-1, IEC/EN 60947-3
- Utilization category:
- AC-22A
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 0.09 kg
- Customs tariff
- 85365080
Level 1 Packaging
- Basic packaging quantity
- 12
- EAN code for a basic packaging
- 3838895297208
- Basic packaging weight
- 1.05 kg
Level 2 Packaging
- Transport packaging quantity
- 108
- EAN code for a transport packaging
- 3838895297215
- Transport packaging weight
- 9.7 kg
- Pallet quantity
- 7020
ETIM Clasification
- Classification
- EC001545
- Class name
- Main switch for distribution board
- Type of drive
- 50/60 Hz
- Degree of protection (IP), front side
- IP20
- Rated voltage DC
- 24
- Number of knife blade fuse holders
- 2
- Switching function
- Off switch with control lamp
- Number of poles
- 2
- Rated current
- 25A
- Rated voltage
- 400V
- Voltage type
- AC
- With signal lamp
- Yes
- Colour calotte
- Other
- Lamp type
- Glow lamp
- Width in number of modular spacings
- 1
- Built-in depth
- 68mm
- Degree of protection (IP)
- IP20
*SL 225 2p 25A
